Other Test

Resistance to Solder Heat、Solderability Test. Inalways standard inspection is in accordance of IEC-60068

Solder Pot

Solder Pot can inspect the high quality of metal terminal of Ac socket after soldering. In addition, the socket shall not have any deformations or fail to function in high temperature.

FUNCTION : Resistance to Solder Heat
ELEMENT : 0~500℃
ACCURACY : ±3℃

Hardness Tester

Hardness Tester can inspect the surface hardness of the copper terminal and ensure mechanical intensity of terminal.

FUNCTION : Hardness Test
HARDNESS : HV、 BHK、 BHBS、 HBW、 Kc Hardness

Plated Thickness Test X-Ray

Plated Thickness Test X-Ray can measure the cladding thickness of terminal and ensure well-soldering and prevent surface-oxidizing of terminal.

FUNCTION : Plated Thickness
ELEMENT : Ti(22)~Pb(88)
ACCURACY : ±0.5%

Solderability

Copper Hardness

Plated Thickness

Grinding / Polishing Machine

Grinding / Polishing Machine can analyze the structure of Inalways product and improve better quality.

FUNCTION : Grinding/Polishing
R.P.M. : 0~500rpm/min

Optical 3D Measuring Machines

FUNCTION : 3D dimensions measurement
MEASURE RANGE : 200 × 150 × 150 mm
MULTIPLE RATE : 17 ~ 410<
PRECISION : Uxy = 2.0 + L/250 μm

Profile Projector

FUNCTION : 2D dimensions measurement
MEASURE RANGE : 150 × 50 mm
MULTIPLE RATE : 10 / 20
PRECISION : ± 0.15 %

Material Analysis

Optical 3D Measuring

Profile Projector
